9
FlashRunner LAN 2.0 Next Generation is composed of a carrier board that hosts up to
4 programming channels.
The engine board on top of it is a System on Module enclosing FlashRunner 2.0 core
technology in a compact and easy to integrate format.
FlashRunner LAN 2.0 Next Generation is available in different enclosures:
▪ FRLAN2P0NXG-OF open frame version
▪ FRLAN2P0NXG-CS closed case version
Figure 1: FlashRunner LAN 2.0 Next Generation in closed case version
FlashRunner LAN 2.0 Next Generation comes in one hardware solution, enabling 1
channel for device programming.
Products upgrade for up to 4 active channels are available by asking your sales
reference for a specific upgrade license.
In all of the above configurations, each ISP channel is composed of:
▪ Eight digital, bidirectional lines;
▪ Two power lines;
▪ Ten ground lines (one per digital signal and power line)
