SMH Technologies FlashRunner LAN 2.0 - Usb Connector; Figure 8: Control Interface Expansion Board

26
You can use the provided expansion board to connect to the control interface’s signals
which are indicated on the board’s silkscreen.
Figure 8: Control Interface expansion board
4.4 USB Connector
The USB-B connector can be used to communicate with the ATE system.
i
Note: USB signals are referenced to GND_USB, separate
from GND, and GND_I.
