15 / 58
Use and maintenance manual BP700AR/310
ENGLISH
2.9 TECHNICAL DATA FOR THE ELECTRIC CONNECTION
2.10 CONDITIONS OF USE
Make sure that there is enough space for easy application and maintenance.
THE MACHINE NEEDS AN INSTALLATION IN A CLOSED AND WELL AIRED
SURROUNDING, WHERE THERE ARE NOT ANY EXPLOSION OR FIRE DANGEROUS.
THE MINIMUM LIGHTING MUST BE 300 LUX.
Position the machine in the planned space with no humidity, flammable materials, gas, and
explosives and making sure that it is level on the floor.
We suggest operating temperatures varying from +10°C to +40°C with a relative humidity from
30% to 80% with no condensation.
SOUND EMISSION PARAMETERS THAT HAVE BEEN DECLARED DISSOCIATED,
IN CONFORMITY WITH THE ISO 4871 REGULATION:
LPFA = 73,1 dB
ASSOCIATED UNCERTAINTY KpA = 4dB
IP class rating = IP33
ATTENTION!
The pressure and the plate acoustical power of the machine can change depending on
the material of containers to be packaged. Therefore, the user must perform an
assessment on the noise exposure of his personnel in accordance with the types of
packages worked, so as to equip his operators with suitable personal protection
equipment.
3. INFORMATION ON THE MACHINE
3.1 MACHINE USE
The ßP700AR/310 film shrink-wrapping machine has been designed, manufactured and sold
to package boxes, jars, magazines, etc. in thermoretractable film packs but without grouping
them.
Earthening is compulsory!
The machine's connection to the mains must be carried out in thorough compliance
with the regulations of the user's country.
Make sure that the frequency and voltage of the machine's power supply (as indicated
on the nameplate to be found on the rear of the machine) correspond to the mains'.
BP700AR/310
RATED VOLTAGE 380-415 V ~
RATED FREQUENCY 50-60 HZ
RATED POWER 1650 W
RATED CURRENT 4.5 A
