39 / 58
Use and maintenance manual BP700AR/310
ENGLISH
6 • Unit MY340035
Pos. Description spare parts Code N. Pos. Description spare parts Code N.
1 ROLLER MH200036 1 9 PLATE MA201359 2
2 RUBBER ROLLER MA700989 1 10 COGGED BELT MF500435 1
3 ROLLER MH200035 1 11 GEAR BOX EM650231 1
4 SPRING MF100440 2 12 MOTOR EM600174 1
5 CAP MN300113 2 13 ROLLER MH200026 4
6 SPRING MF100628 2 14 CAP MF801115 1
7 PIVOT MA102547 2 15 BUSH MA111896 2
8 PIVOT MA600023 2 16 SUPPORT MF801112 1
