18 / 58
2 • Wrapping and film sealing section:
• Check the film tension.
• Check that there are no breakings on the sealing bar.
• Test the blade and check if there are broken or folded teeth (be very careful when working
near the blade, use protection gloves when handling ).
3 • Pneumatic section:
• Test the air pipes and check that there are no leakages.
• Check that the pipes are not disconnected from the fittings.
• Clean the filter on the air duct
3.10 FIRST FILM SEALING
4. PREPARATION TO THE USE OF THE MACHINE
4.1 MACHINE START-UP
Fig. 3.10.1
The insertion or replacement of the
reels must be performed with the
machine switched off.
Center the reels on the relative
rollers 1 paying attention to sharp
or pointed surfaces. At this point
move the clamps 2 leaving a few
millimeters between the same and
the reel.
Make the film go through the
tensioning bars as in fig. 4.6.2.
Position and overlap the two edges
of the film 3 over the sealing bar.
Close the safety door and switch
on the machine and start the first
sealing,
(See Paragraph
4.3“MANUAL SELECTION”’at pag. 19)
and then remove wastage.
Turn the control panel's general switch to pos. ON. Then press the [POWER] key to
start the machine. The temperature of the sealing bar and the number of the
programme that is being used (es.M1) will appear on the viewer.
Fig. 3.10.2
