Section 4 Scanner
This section describes the basic operation of the Scanner function.
The Scanner icon is located on the Home screen.
The Scanner function allows your diagnostic tool to communicate
with the control modules of the motorcycle being serviced. This
allows you to perform tests, view diagnostic trouble codes (DTCs),
and live data parameters from various vehicle systems such as the
engine, antilock brakes (ABS), body control module and more.
This manual is intended to be used for P1000 motorcycle scanner
operations. For automotive operations, see the Ethos Edge user manual
at: http://diagnostics.snapon.com/usermanuals
Main Topic Links
• Scanner Overview page 10
• Scanner Demonstration Mode page 11
• Features and Icons page 12
• Scanner - Starting / Stopping page 11
• Scanner Control Icons page 12
• Basic Scanner Operation (Quick Start) page 13
• Data Cable Connection page 13
• Vehicle Identification / System Selection page 14
• System Main Menu Options page 16
• Codes - View / Scan / Save page 17
• Code Scan page 17
• Viewing and Saving Data page 20
• Using Triggers page 27
• Trigger Description and Features page 27
• Functional Tests page 30
4.1 Basic Operation
4.1.1 Scanner Overview
Scanner is a menu driven application that communicates with control modules to
access diagnostic trouble codes (DTCs), parameter data (PIDs), functional tests, and
more. To navigate the application, use your fingertip or the control buttons to make
onscreen menu selections to access the desired data, test or function.
Screen messages appear when additional input is needed before proceeding. There
are three types of on-screen messages; confirmations, warnings, and errors.
• Confirmation Messages - Confirmation messages inform you when you are
about to perform an action that cannot be reversed or when an action has been
initiated and your confirmation is needed to continue. When a user-response is
not required to continue, the message displays briefly before automatically
disappearing.
• Warning Messages - Warning messages inform you when completing the
selected action may result in an irreversible change or loss of data.
• Error Messages - Error messages inform you when a system or procedural
error has occurred.
