38
Scanner Scanner Operation
Use the slider to quickly scroll through the data. Use the control icons to accurately position
the cursor. The cursor (vertical line), indicates your position when in the graph mode, appears
once you begin navigating (Figure 4-17).
Figure 4-17
2. Scroll up or down to review the list of data.
3. Select the desired control icon to move forward or back incrementally in the selected direction.
z To resume:
• Select the Record icon.
The display changes back to display data and the Pause icon is shown on the toolbar. A
vertical rule runs through the data graph to indicate data was paused at that point.
i The Shortcut icon can be set to perform the Pause/Play function. See Configure Shortcut Button,
on page 57 for additional information.
1— Skip Back
2— Skip Forward
3— Step Back
4— Step Forward
5— Record
6— Bar Graph
7— Slider
8— Counter (current position / total)
9— Cursor
