Identify the two Linear Modules labeled with "Z" on the
cable connector. They will be the Z axes.
Z-axis Linear Module × 2
All the Linear Modules must be installed in their intended position. Incorrect installation or
mixed use of the Linear Modules will result in malfunction of or damage to the machine.
07
/22
A7
It does not matter if the slider position of your Z axis differs from the illustration until Step 13.
