Snapmaker Artisan - Page 36

32-33
Machine Assembly
Insert the dowels of the base plate into the dowel holes
of the Z-axis holders, and attach the Z-axis holders to
the base plate with screws.
12
/22
1:1
M5 × 12 Screw × 8
Make sure to fully insert the dowels into
the dowel holes.
