52
You can also erect
the bottom frame and
install the columns as
illustrated.
Attach the column-1 (with hinge) to the bottom frame.
05
/28
M5 × 30 Screw × 2
1:1
Column-1 (with hinge
)
× 1 B1
Make sure
the limit bars
of the profile
connectors are
inside the column
grooves.
