Enclosure
The rightmost cable hole is reserved for the extension cable of the Rotary Module (for 4-axis
machining), which is available for purchase on our online store.
Whether or not the first function you will experience is 3D
printing, you need to thread the heated bed cable through the
cable pass-through fixture in this step.
Ensure that
the three
yellow locating
labels are all
underneath the
cable pass-
through fixture.
Other
Cables
X-axis
Cable
Heated
Bed Cable
Toolhead
Cable
Thread the cables through the corresponding hole of the cable pass-
through fixture, and then attach the fixture to the short beam (rear).
21
/28
M5 × 30 Screw × 2
Cable Pass-through Fixture × 1 A5
