74-75
Enclosure
M5 × 16 Low Head Cap Screw × 10
1:1
Do not over-tighten the screws lest the panel should be damaged.
You can install the two uppermost
screws first, hang the back panel on
them, and then install the other screws.
It is recommended to pre-tighten the screws near the corners first, then pre-tighten the
remaining screws, and finally tighten all the screws in the pre-tightening order.
Attach the back panel to the frame.
24
/28
To Next Page
