It is recommended to place the integrated controller on the right side of the Enclosure to make
it easier for you to operate the Touchscreen when the Enclosure door is open.
Ensure that the
connector is in the
correct direction.
Place the Integrated Controller within easy reach so that you can press the emergency stop
button on top of the controller to respond quickly to an emergency.
Plug the toolhead cable, the Enclosure cable, the
heated bed cable, and the Linear Module cables into
the Integrated Controller.
26
/28
Integrated Controller × 1 A1
To Next Page
