BTP-M280 User’s Manual
- 4 -
2 Specifications
2.1 Main Specification
Item Specification
Print mode 9-pin serial impact dot matrix
Print speed Max. 4.7LPS (400 dots/line)
Print width Max. 400(half dots)/200(full dots)
Paper type Continuous paper or marked paper
Single layer
Paper width: 80±0.5mm, 76±0.5mm, 69.5±0.5mm, 57.5±0.5mm;
Paper thickness: 0.06—0.085mm
Paper
Multi-layer paper
(1 original+1 copies)
Paper width: 80±0.5mm, 76±0.5mm, 69.5±0.5mm, 57.5±0.5mm;
Paper thickness: 0.05—0.08mm, total thickness≤0.14 mm
Character type Font A: 9×9 Font B: 7×9 Chinese: 16×16
80/76mm 69.5mm 57.5mm
Font A 33 CPL 30 CPL 25 CPL
Font B 40 CPL 36 CPL 30 CPL
Characters/line (Default)
Chinese 22 CPL 20 CPL 16 CPL
Character size (Default) Font A: 1.6×3.1mm Font B: 1.2×3.1mm Chinese: 2.7×2.9mm
Character
Characters/inch (Default) Font A: 13.3CPI Font B: 16CPI Chinese: 8.9CPI
Receive buffer 4KB
NV bit image data area 128KB
Data
buffer
User NV memory 8KB
Ribbon specification ERC-38 ribbon cartridge
ERC-38(P) 4,000,000 characters
ERC-38(B) 3,000,000 characters
Ribbon lifetime
ERC-38(B/R)
Black: 1,500,000 characters
Red: 750,000 characters
Communication interface USB (Fixed) + IEEE1284/RS-232/Ethernet / Wi-Fi interface (optional)
Cash drawer connector 1～2 cash drawers
Power supply DC 24V±5% average current 1.5 A
Printing Mechanism lifetime 10,000,000 lines
Print head lifetime 150,000,000 characters
Reliability
Cutter 1,000,000 times
Operating temperature and humidity 5～45℃，20～90%RH (40℃)
Storage temperature and humidity -40～60℃，20%～93%RH (40℃)
Dimensions 160mm(W)×245mm(D)×145mm(H)
Weight 2.9kg
