UPS/NTA GB/DMX-DMP JBUS.D Page 10 / 22
…/…
CODE DESCRIPTION BIT ADRESSE REMARQUES
S64 Boost charge ON 0 0x1024
S65 1 0x1024
S66 Inverter switch closed 2 0x1024
S67 Bypass breaker closed 3 0x1024
S68 Maintenance bypass breaker closed (Q5) 4 0x1024
S69 Remote maintenance bypass breaker closed 5 0x1024
S70 Output breaker closed (Q3) 6 0x1024
S71 Q21 closed 7 0x1024
S72 Q22 closed 8 0x1024
S73 Unit working 9 0x1024 On inverter or on bypass
S74 10 0x1024
S75 11 0x1024
S76 normal mode active 12 0x1024 No Eco-mode No ‘energy-
saver’ active
S77 13 0x1024
S78 14 0x1024
S79 15 0x1024
S80 0 0x1025
S81 1 0x1025
S82 2 0x1025
S83 3 0x1025
S84 4 0x1025
S85 5 0x1025
S86 6 0x1025
S87 7 0x1025
S88 8 0x1025
S89 9 0x1025
S90 10 0x1025
S91 11 0x1025
S92 12 0x1025
S93 13 0x1025
S94 14 0x1025
S95 15 0x1025
Status without description are not managed by DELPHYS MX / MP.
