UPS/NTA GB/DMX-DMP JBUS.D Page 11 / 22
5. ALARMS: Address 0x1040, 4 words
CODE DESCRIPTION BIT ADRESSE REMARQUES
A00 General Alarm 0 0x1040 Activated if one alarm
active
A01 Battery failure 1 0x1040 Battery fault, room and
circuit open synthesis
A02 UPS overload 2 0x1040
A03
A04 Control failure (com, internal supply…) 4 0x1040 Ctrl board critical alarm
A05 Rectifier input supply out of tolerance 5 0x1040
A06 Bypass input supply out of tolerance 6 0x1040
A07 Over temperature alarm 7 0x1040
A08 Maintenance bypass closed 8 0x1040 Q5 closed
A09 9 0x1040
A10 Battery charger fault 10 0x1040
A11 11 0x1040
A12 12 0x1040
A13 13 0x1040
A14 14 0x1040
A15 15 0x1040
A16 0 0x1041
A17 Improper condition of use (Q3 and Q5
closed)
1 0x1041 Maintenance bypass alarm
A18 Inverter stopped for overload
(or bypass transfer)
2 0x1041 Imminent stop and
overload
A19 Microprocessor control system 3 0x1041 Ctrl board preventive Al.
A20 4 0x1041
A21 Synchronisation fault (PLL fault) 5 0x1041 ACS source fault
A22 Rectifier input supply fault 6 0x1041
A23 Rectifier preventive alarm 7 0x1041
A24 8 0x1041
A25 Inverter preventive alarm 9 0x1041
A26 Charger general alarm 10 0x1041
A27 11 0x1041
A28 12 0x1041
A29 Bypass preventive alarm 13 0x1041
A30 14 0x1041
A31 Imminent STOP 15 0x1041
A32 Unit 1 general alarm 0 0x1042
A33 1 0x1042
A34 2 0x1042
A35 3 0x1042
A36 4 0x1042
A37 5 0x1042
A38 External alarm 6 0x1042 To configure
A39 7 0x1042
A40 8 0x1042
A41 9 0x1042
A42 e-Service 10 0x1042 NOT AVAILABLE
A43 11 0x1042
A44 Servicing alarm 12 0x1042
A45 Automatic and manual transfer disable 13 0x1042
A46 Automatic transfer disable 14 0x1042
A47 Battery room alarm 15 0x1042
A48 Maintenance bypass alarm 0 0x1043
A49 Battery discharged 1 0x1043
A50 2 0x1043
A51 Synoptic alarm 3 0x1043
A52 Rectifier fault 4 0x1043 Critical alarm
A53 5 0x1043
A54 Inverter fault 6 0x1043 Critical alarm
A55 7 0x1043
A56 8 0x1043
A57 9 0x1043
A58 ESD activated 10 0x1043
A59 Battery circuit open 11 0x1043
A60 12 0x1043
A61 13 0x1043
A62 Bypass critical alarm 14 0x1043
A63 15 0x1043
Alarms without description are not managed by DELPHYS MX / MP.
