UPS/NTA GB/DMX-DMP JBUS.D Page 17 / 22
Preliminary remarks
The following
J
J
B
B
U
U
S
S
/
/
M
M
O
O
D
D
B
B
U
U
S
S addresses tables only indicate the LSB byte, the MSB depends of the
module number requested.
An ‘X’ in the ‘CC’ (central bypass), ‘Module’ or ‘Unit’ column means that this information is available on
this equipment.
Please refer to § 4.4 for more details.
4. STATUS : Address 0x20, 6 words
CODE DESCRIPTION BIT ADDRESS LSB
byte
CC Module Unit
S00 Rectifier Input supply present 0 0x20
X X
S01 Inverter ON 1 0x20
X X
S02 Rectifier ON 2 0x20
X X
S03 Load protected by inverter 3 0x20
X X X
S04 Load on automatic bypass 4 0x20
X X
S05 Load on battery / Battery discharging 5 0x20
X X
S06 Remote controls disable 6 0x20
X
S07 Eco-mode ON 7 0x20
X X X
S08 8 0x20
S09 9 0x20
S10 10 0x20
X X
S11 11 0x20
S12 12 0x20
S13 13 0x20
S14 Battery test failed 14 0x20
X X
S15 Battery near end of backup time 15 0x20
X X
S16 Battery discharged 0 0x21
X X
S17 Battery OK 1 0x21
X X
S18 2 0x21
S19 3 0x21
S20 4 0x21
S21 5 0x21
S22 6 0x21
S23 7 0x21
X X
S24 8 0x21
X X
S25 9 0x21
S26 Bypass input supply present 10 0x21
X X
S27 Battery charging 11 0x21
X X
S28 Bypass input frequency out of
tolerance
12 0x21
X X
S29 13 0x21
S30 UPS on parallel system 14 0x21
X X X
S31 15 0x21
S32 Unit 1 operating 0 0x22
X X
S33 Unit 2 operating 1 0x22
X X
S34 Unit 3 operating 2 0x22
X X
S35 Unit 4 operating 3 0x22
X X
S36 Unit 5 operating 4 0x22
X X
S37 Unit 6 operating 5 0x22
X X
S38 External Input 1 6 0x22
X X X
S39 External Input 2 7 0x22
X X X
S40 External Input 3 8 0x22
X X X
S41 External Input 4 9 0x22
S42 Controls permission table manage 10 0x22
X X X
S43 11 0x22
S44 12 0x22
S45 13 0x22
S46 Operating on Gen Set 14 0x22
X X X
S47 15 0x22
…/…
