UPS/NTA GB/DMX-DMP JBUS.D Page 18 / 22
…/…
CODE DESCRIPTION BIT ADDRESS
LSB byte
CC Module Unit
S48 Maintenance mode active 0 0x23
X X X
S49 End of the fist maintenance period 1 0x23
S50 2 0x23
S51 3 0x23
S52 4 0x23
S53 5 0x23
S54 6 0x23
S55 7 0x23
S56 8 0x23
S57 9 0x23
S58 10 0x23
S59 11 0x23
S60 12 0x23
S61 13 0x23
S62 14 0x23
S63 15 0x23
S64 Boost charge ON 0 0x24
X X
S65 1 0x24
X X
S66 Inverter switch closed 2 0x24
X X
S67 Bypass breaker closed 3 0x24
S68 Maintenance bypass breaker closed (Q5) 4 0x24
X X
S69 Remote maintenance bypass breaker closed 5 0x24
X X
S70 Output breaker closed (Q3) 6 0x24
X X X
S71 Q21 closed 7 0x24
X X
S72 Q22 closed 8 0x24
X X
S73 Unit working 9 0x24
X X
S74 Energy saver activated 10 0x24
X X X
S75 11 0x24
S76 normal mode active 12 0x24
X X X
S77 13 0x24
S78
14 0x24
S79
15 0x24
S80
0 0x25
S81
1 0x25
S82
2 0x25
S83
3 0x25
S84
4 0x25
S85
5 0x25
S86
6 0x25
S87
7 0x25
S88
8 0x25
S89
9 0x25
S90
10 0x25
S91
11 0x25
S92
12 0x25
S93
13 0x25
S94
14 0x25
S95
15 0x25
