UPS/NTA GB/DMX-DMP JBUS.D Page 7 / 22
SINGLE UNIT UPS JBUS/MODBUS TABLES
JBUS/MODBUS tables
§ TABLE
Start
addresses
Table length in
words
JBUS/MODBUS
FUNCTION
1 UPS Identification 0x1000 12 3 READ
2 Date and hours 0x1360 4 3 READ
3 UPS Configurations 0x10E0 32 3 READ
4 Status (96 bits) 0x1020 6 3 READ
5 Alarms (64 bits) 0x1040 4 3 READ
6 Measurements 0x1060 48 3 READ
7 Controls permission 0x15C0 2 3 READ
8 UPS Controls 0x15B0 1 6 WRITE
How to read data:
The identification, status and alarms tables should be read completely (this means the number of word to
read is equal to the table length).
The measurements table could be read word by word or per group, without exceed the length of the table.
(from 0x1060 to 0x108F).
Incoming data structure:
Example of 6 words
1 2 3 4 5 6 7 8 9 10 11 12
MSB 0 LSB 0 MSB 1 LSB 1 MSB 2 LSB 2 MSB 3 LSB 3 MSB 4 LSB 4 MSB 5 LSB 5
WORD 0 WORD 1 WORD 2 WORD 3 WORD 4 WORD 5
b
15
b
0
b
15
b
0
b
15
b
0
b
15
b
0
b
15
b
0
b
15
b
0
S15 S00 S31 S16 S47 S32 S63 S48 S79 S64 S95 S80
A15 A00 A31 A16 A47 A32 A63 A48
M00 M01 M02 M03 M04 M05
‘Concentrator mode’ in parallel system configuration
The above
J
J
B
B
U
U
S
S
/
/
M
M
O
O
D
D
B
B
U
U
S
S
table can be used in case of a parallel system configuration. The TOR data
from all units or modules are managed in order to create a ‘virtual single unit’. The logic combination ‘OR’ is
used to create the single unit data base, except following states and alarms :
Information
Combination if redundant UPS Combination if not redundant UPS
S00 OR AND
S05 AND OR
S15 AND OR
A02 AND OR
A07 AND OR
A31 AND OR
