JBUS/MODBUS tables in parallel system configuration with central bypass (AC)
TABLE Start addresses Table length in words
JBUS/MODBUS
FUNCTION
Identification 0x8000 12 3 READ
Configurations 0x80E0 32 3 READ
Date and hours 0x8360 4 3 READ
States CC ( 96 bits) 0x8020 6 3 READ
Alarms CC ( 64 bits) 0x8040 4 3 READ
Measurements CC 0x8060 48 3 READ
States module 1 ( 96 bits) 0x2020 6 3 READ
Alarms module 1 ( 64 bits) 0x2040 4 3 READ
Measurements module 1 0x2060 48 3 READ
States module 2 ( 96 bits) 0x3020 6 3 READ
Alarms module 2 ( 64 bits) 0x3040 4 3 READ
Measurements module 2 0x3060 48 3 READ
States module 3 ( 96 bits) 0x4020 6 3 READ
Alarms module 3 ( 64 bits) 0x4040 4 3 READ
Measurements module 3 0x4060 48 3 READ
States module 4 ( 96 bits) 0x5020 6 3 READ
Alarms module 4 ( 64 bits) 0x5040 4 3 READ
Measurements module 4 0x5060 48 3 READ
States module 5 ( 96 bits) 0x6020 6 3 READ
Alarms module 5 ( 64 bits) 0x6040 4 3 READ
Measurements module 5 0x6060 48 3 READ
States module 6 ( 96 bits) 0x7020 6 3 READ
Alarms module 6 ( 64 bits) 0x7040 4 3 READ
Measurements module 6 0x7060 48 3 READ
Controls permission 0x15C0 2 3 READ
UPS Controls 0x15B0 1 6 WRITE
JBUS/MODBUS table in modular parallel system
TABLE
Start addresses Table length in words
JBUS/MODBUS
FUNCTION
Identification
0x1000 12 3 READ
Configurations UPS
0x10E0 32 3 READ
Date and hours
0x1360 4 3 READ
Output UPS Measurements
0x8060 48 3 READ
States unit 1 ( 96 bits)
0x2020 6 3 READ
Alarms unit 1 ( 64 bits)
0x2040 4 3 READ
Measurements unit 1
0x2060 48 3 READ
States unit 2 ( 96 bits)
0x3020 6 3 READ
Alarms unit 2 ( 64 bits)
0x3040 4 3 READ
Measurements unit 2
0x3060 48 3 READ
States unit 3 ( 96 bits)
0x4020 6 3 READ
Alarms unit 3 ( 64 bits)
0x4040 4 3 READ
Measurements unit 3
0x4060 48 3 READ
States unit 4 ( 96 bits)
0x5020 6 3 READ
Alarms unit 4 ( 64 bits)
0x5040 4 3 READ
Measurements unit 4
0x5060 48 3 READ
States unit 5 ( 96 bits)
0x6020 6 3 READ
Alarms unit 5 ( 64 bits)
0x6040 4 3 READ
Measurements unit 5
0x6060 48 3 READ
States unit 6 ( 96 bits)
0x7020 6 3 READ
Alarms unit 6 ( 64 bits)
0x7040 4 3 READ
Measurements unit 6
0x7060 48 3 READ
