UPS/NTA GB/DMX-DMP JBUS.D Page 9 / 22
4. STATUS: Address 0x1020, 6 words
CODE DESCRIPTION BIT ADDRESS REMARKS
S00 Rectifier Input supply present 0 0x1020
S01 Inverter ON 1 0x1020
S02 Rectifier ON 2 0x1020
S03 Load protected by inverter 3 0x1020
S04 Load on automatic bypass 4 0x1020
S05 Load on battery 5 0x1020
S06 Remote controls disable 6 0x1020 0 = controls enabled
S07 Eco-mode ON 7 0x1020 If this function is available
S08 8 0x1020
S09 9 0x1020
S10 10 0x1020
S11 11 0x1020
S12 12 0x1020
S13 13 0x1020
S14 Battery test failed 14 0x1020
S15 Battery near end of backup time 15 0x1020 IMMINENT STOP and end of backup
time
S16 Battery discharged 0 0x1021
S17 Battery OK 1 0x1021 No alarm and battery circuit
closed
S18 2 0x1021
S19 3 0x1021
S20 4 0x1021
S21 5 0x1021
S22 6 0x1021
S23 7 0x1021
S24 8 0x1021
S25 9 0x1021
S26 Bypass input supply present 10 0x1021
S27 Battery charging 11 0x1021
S28 Bypass input frequency out of
tolerance
12 0x1021
S29 13 0x1021 Set to 1
S30 UPS on parallel system 14 0x1021 = 0 for single unit
S31 15 0x1021
S32 Unit operating (available or
coupled)
0 0x1022
S33 1 0x1022
S34 2 0x1022
S35 3 0x1022
S36 4 0x1022
S37 5 0x1022
S38 External Input 1 6 0x1022 IN1 ADC slot 1 or 2
S39 External Input 2 7 0x1022 IN2 ADC slot 1 or 2
S40 External Input 3 8 0x1022 IN3 ADC slot 1 or 2
S41 External Input 4 9 0x1022 IN1 ADC slot 3
S42 Controls permission table manage 10 0x1022 Set to 1
S43 11 0x1022
S44 12 0x1022
S45 13 0x1022
S46 Operating on Gen Set 14 0x1022
S47 15 0x1022
S48 Maintenance mode active 0 0x1023
S49 End of the fist maintenance period 1 0x1023
S50 2 0x1023
S51 3 0x1023
S52 4 0x1023
S53 5 0x1023
S54 6 0x1023
S55 7 0x1023
S56 8 0x1023
S57 9 0x1023
S58 10 0x1023
S59 11 0x1023
S60 12 0x1023
S61 13 0x1023
S62 14 0x1023
S63 15 0x1023
…/…
