9) Min. Discharge (V)
Select “6. Min. Discharge (V)” and press “OK”. Press “up” or “down” to change the 1
st
digit, press “ok” to switch
to next digit. Input the value of Min. Discharge (V) per battery specification. Press “OK”.
10) * Empty Discharged (V) (only for DEFAULT battery type)
Select “10. Empty Discharged (V)” and press “OK”. Press “up” or “down” to change the 1
st
digit, press “ok” to
switch to next digit. Input the value of Empty Discharged Voltage per battery specification. Press “OK”.
11) * Full Charged (V) (only for DEFAULT battery type)
Select “11. Full Charged (V)” and press “OK”. Press “up” or “down” to change the 1
st
digit, press “ok” to switch to
next digit. Input the value of Full Charged Voltage per battery specification. Press “OK”.
12) Save
Select “12. Save” and press “OK” to save all battery parameters.
2. Clear Energy Data
Select “2. Clear Energy” and press “OK”, “input password” is shown. Input the password “0001”, press “Up” or
“Down” to change the 1
st
digit, press “OK” to switch to next digit, when “0001” is shown on the screen, press
“OK”. If “Incorrect, Try Again!” is shown on the screen, press “Back” and input the password again.
3. Clear Events
Select “3. Clear Events”, press “OK” button twice to clear all the events.
4. Set Country (refer to Set country
)
Select “4. Set Country”, press “OK”, current country setting is shown, input new country code & press “OK”
If “Set Disable” is shown, you need to go to “6. Function to Set Country” to enable country setting first.
5. Set Communication Addr.
Select “5. Set Communication Addr.”, press “OK”. Press “Up” or “Down” to change the 1
st
digit, press “OK” to
switch to next digit, after changing the 485-communication address, press “OK”.
6. Function to Set Country
Select “6. Function to Set Country”, press “OK”, “input password” is shown. Input the password “0001”, press “Up”
or “Down” to change the 1
st
digit, press “OK” to switch to next digit, when “0001” is shown on the screen, press
“OK”. If “Incorrect, Try Again!” is shown on the screen, press “Back” and input the password again.
7. Set Language
Select “7. Set Language”, press “OK”. Press “up” or “down” to select the language and press “OK”.
Easier Way: press “Back” & “OK” at the same time to change system language.
8. Set Time
Select “8.Set Time”, press “OK” to enter time setting interface, system time format is 20YY-MM-DD HH:MM:SS.
Press “Up” or “Down” to change the 1
st
digit, press “OK” to switch to next digit, after inputting the current time,
press “OK”.
