Sofar ME3000SP User Manual

29
9. Set EPS (Emergency Power Supply) Mode
9. Set EPS Mode
1.EPS Mode Control
1.Enable EPS Mode
2.Disable EPS Mode
2.Set EPS Changeover Time ***S
10. DRMs0 Control (ONLY for Australian Market)
Select “10. DRMs0 Control”, press “OK”, “input password” is shown. Input the password “0001”, press “Up” or
“Down” to change the 1
st
digit, press “OK” to switch to next digit, when “0001” is shown on the screen, press
“OK”.
After entering DRMs0 control interface, press “up” or “down” to select “1. Enable DRMs0” or “2. Disable DRMs0”,
press “OK”.
11. Auto Test (ONLY for Italian Market)
Select “11. Auto Test”, press “OK” to enter autotest interface.
11.Auto Test
1.Autotest Fast
2.Autotest STD
3.QF Time Setting
4.QV Time Setting
5.Control 81.S1
1) Autotest Fast
Select “1. Autotest Fast”, then press “OK” to start Auto test Fast.
Start Autotest
↓
Press “Ok” to start
Testing 59.S1...
↓
Wait
Test 59.S1 OK!
↓
Wait
Testing 59.S2...
↓
Wait
Test 59.S2 OK!
↓
Wait
Testing 27.S1...
↓
Wait
Test 27.S1 OK!
↓
Wait
Testing 27.S2...
↓
Wait
Test 27.S2 OK!
“Up” ↑
“Down”↓

Sofar ME3000SP Specifications

General

Model	ME3000SP
Manufacturer	Sofar Solar
Type	Hybrid Inverter
Rated Power	3000 W
Max PV Input Voltage	500 V
Max PV Input Current	13 A
Battery Voltage Range	40-60 V
Efficiency	97.5%
Max. DC Voltage	500 V
Number of MPPTs	1
Max. Input Current per MPPT	13 A
Max. AC Power	3000 W
Max. AC Current	13.6 A
Rated AC Voltage	230 V
AC Voltage Range	180-280V
Rated Frequency	50/60 Hz
THDi	<3%
Euro Efficiency	97%
DC Switch	Yes
Protection Degree	IP65
Operating Temperature Range	-25°C to +60°C
Cooling	Natural Convection
Communication	RS485, WiFi (optional)
