Sofar ME3000SP User Manual

31
2) Autotest STD
Select “2. Autotest STD”, then press “OK” to start Auto test STD.
The test procedure is same as Autotest Fast, but it’s much more time consuming.
3) PF Time Setting
Select “3. PF Time Setting”, then press “OK”. The following will be shown on the display:
Set: *. *** s
Press “Up” or “Down” to change the 1
st
digit, press “OK” to switch to next digit. After changing all digits, press
“OK”.
4) QV Time Setting
Select “4. QV Time Setting”, then press “OK”. The following will be shown on the display:
Set：** s
Press “Up” or “Down” to change the 1
st
digit, press “OK” to switch to next digit. After changing all digits, press
“OK”.
5) Control 81.S1
Select “5.Control 81.S1”. then press “OK”. Press “up” or “down” to select “1. Enable 81.S1” or “2. Disable 81.S1”,
press “OK”.
12. Work Mode Set
Select “12. Work Mode Set”, press “OK” to enter work mode setting interface.
12.Work Mode Set
1.Set Auto Mode
2.Set Time-of-use Mode
3.Set Timing Mode
4.Set Passive Mode
1) Set Auto Mode
Select “1. Set Auto Mode”, then press “OK”.
In auto mode, ME3000SP will automatically charge & discharge the battery.
“Up” ↑
“Down”↓

Sofar ME3000SP Specifications

General

Model	ME3000SP
Manufacturer	Sofar Solar
Type	Hybrid Inverter
Rated Power	3000 W
Max PV Input Voltage	500 V
Max PV Input Current	13 A
Battery Voltage Range	40-60 V
Efficiency	97.5%
Max. DC Voltage	500 V
Number of MPPTs	1
Max. Input Current per MPPT	13 A
Max. AC Power	3000 W
Max. AC Current	13.6 A
Rated AC Voltage	230 V
AC Voltage Range	180-280V
Rated Frequency	50/60 Hz
THDi	<3%
Euro Efficiency	97%
DC Switch	Yes
Protection Degree	IP65
Operating Temperature Range	-25°C to +60°C
Cooling	Natural Convection
Communication	RS485, WiFi (optional)
