Creating Logical and Physical Layout using Installation
Information
To display a logical layout, insert in the new site created in the monitoring platform.
When the communication between the and the monitoring server is established, the
logical layout is displayed.
To display a physical layout, you need to map the locations of the installed power
optimizers. To map the locations, use one of the methods described in the next sections.
Designer
Designer recommends inverter and Power Optimizer selection per site size and enables
report generation. You can create a project in Designer and export the site design with
the PV array layout to the monitoring platform.
For more information, refer to https://www.solaredge.com/products/installer-
tools/designer#/.
Physical Layout Editor
1. If you are a registered installer, access the monitoring platform site creation page at
https://monitoring.solaredge.com/solaredge-web/p/home#createSites. If you have
not yet signed up, go to https://monitoring.solaredge.com/solaredge-
web/p/createSelfNewInstaller.
2. Fill out all required information in the screen, which includes information about your
installation, as well as details about its logical and physical mapping.
Signaling Options
Alternative Power Source
Energy-generation systems (such as PV inverters) connected to the grid may consist of
different types of energy generating sources.
In some cases, when grid power is disconnected, PV inverters operate in parallel with
other voltage sources, such as generators.
When inverters operate concurrently with generators, they may be subjected to voltage
and frequency fluctuations that exceed trips, which are preset according to regional
grid connection requirements. To support simultaneous operation of the inverter and a
generator, the inverter extends its Voltage and frequency operating range once it
receives a Power Reduction Interface (PRI) signal indicating that grid power is
Chapter 6: Activating, Commissioning and Configuring the System83
Three Phase Inverters with Synergy Technology PN: SExxK-xxxxIxxxx
