Utility authorization is required to change abnormal voltage and frequency set-points.
Response to abnormal conditions and untentional islanding results in a disconnect of
the equipment from the area EPS.
Enter Service Settings
Function
IEEE 1547 Default Settings
(1)
Range
Enter Service Delay
300
(2)
0-1000 seconds
Enter Service Ramp Period 100 1-1000 seconds
Minium voltage 0.917 0.88-0.95 p.u.
Maxium voltage 1.05 1.05 -1.05 p.u.
Minium frequency 59.5 59.0-59.9 Hz
Maxium Frequency 60.1 60.1-61.0 Hz
Grid Support Functions
Function IEEE 1547 Default Settings
(1)
Range
Constant Power Factor
mode
1 0-1
Constant Reactive power
mode
Disabled +/- 1 nameplate Var p.u.
Voltage-Reactive power
mode
Disabled
V2 0.98 0.92 -1.05 V p.u.
Q2 0 +/- 1 nameplate Var p.u.
V3 1.02 0.95 -1.08 V p.u.
Q3 0 +/- 1 nameplate Var p.u.
V1 0.92 0.77-1.03 V p.u.
Q1 0.44 0-1 nameplate Var p.u.
V4 1.08 0.97-1.23 V p.u.
Q4 -0.44 (-1)-0 nameplate Var p.u.
(1)
Settings will be specified by the regional EPS (electric power system) operator.
(2)
Changes to this setting should not be made without approval from the area EPS operator
Three Phase Inverters with Synergy Technology PN: SExxK-xxxxIxxxx
100 Enter Service Settings
