SolarEdge SE5K User Manual

Indication
ON/ OFF/
P
switch
position
LEDcolor
Comment
Red Green Blue
Inverter is OFF
(Safe DC)
 OFF (0)
OFF Blinking
S_OK: ON
No S_OK:
OFF

Inverter is OFF
(DC not safe)
Blinking Blinking
S_OK: ON
No S_OK:
OFF

Inverter
configuration
or reboot
ON / P ON ON ON 
Inverter
firmware
upgrade
ON / P Alternating Alternating Alternating
The upgrade
process can take
up to 5 minutes
Error Any ON
ON/ OFF/
Blinking/
Flickering
ON/ OFF /
Blinking
Refer to Errors
and
Troubleshooting
on page 62
The following table describes producution percentage of AC information by LED color
and ON/OFF/P switch position.
Indication
ON/
OFF/ P
switch
position
LEDcolor
Comment
Red Green Blue
Percentage of AC
Production:
0 %
 ON (1)
OFF OFF OFF
This indicates
power
production as
percentage of
rated peak AC
output power
Percentage of AC
Production:
0 - 33 %
OFF ON OFF
Percentage of AC
Production:
33 - 66 %
OFF OFF ON
Percentage of AC
Production:
66 - 100 %
OFF ON ON

-Three Phase System Installation Guide MAN-01-00505-1.2
24 Inverter Interfaces

SolarEdge SE5K Specifications

General

Model	SE5K
Manufacturer	SolarEdge
AC Output Power	5000 W
Rated AC Power	5000 W
Max. Efficiency	98.3%
Cooling	Natural convection
Protection Rating	IP65
Max. Input DC Voltage	480 V
Max. Input Current	11 A
Number of MPP Trackers	1
Warranty	12 years
Communication Interfaces	RS485, Ethernet
AC Voltage	230 V
Operating Temperature Range	-25°C to +60°C
MPPT Voltage Range	330-480V
