SolarEdge SE5K User Manual

Technical Specifications - Three Phase Inverters
(Europe &APAC)
SE4K - SE12.5K
 SE4K SE5K SE7K SE8K SE9K SE10K SE12.5K Unit
Output
Rated AC power
output
4000
(1)
5000 7000 8000 9000 10000 12500 VA
Maximum AC power
output
4000 5000 7000 8000 9000 10000 12500 VA
AC Output Line
Connections
 3 phase, 4-wire / PE (L1-L2-L3-N), TN, TT 
AC output voltage –
line to line / line to
neutral (nominal)
380/ 220; 400/ 230 Vac
AC output voltage
range
184 – 264.5 Vac
AC frequency 50/60 ± 5 Hz
Maximum
continuous output
current (per phase)
6.5 8 11.5 13 14.5 16 20 A
Maximum
continuous
overcurrent
protection
6.5 8 11.5 13 14.5 16 20 A
Residual current
detector / Residual
Current step detector
300 / 30 mA
Grid supported –
three phase
3 / N / PE (WYE with Neutral) 
Inrush current AC
(Peak/Duration)
3/ 20
Aac
(rms)
/ ms
Maximum output
fault current
33 A
Power factor range 1 (adjustable from -0.9 to +0.9) 
(1)
SE4K model is available in some countries; refer to the Certifications category in
http://www.solaredge.com/groups/support/downloads
-Three Phase System Installation Guide MAN-01-00505-1.2
86 Technical Specifications - Three Phase Inverters (Europe &APAC)

SolarEdge SE5K Specifications

General

Model	SE5K
Manufacturer	SolarEdge
AC Output Power	5000 W
Rated AC Power	5000 W
Max. Efficiency	98.3%
Cooling	Natural convection
Protection Rating	IP65
Max. Input DC Voltage	480 V
Max. Input Current	11 A
Number of MPP Trackers	1
Warranty	12 years
Communication Interfaces	RS485, Ethernet
AC Voltage	230 V
Operating Temperature Range	-25°C to +60°C
MPPT Voltage Range	330-480V
