Chapter 4: Connecting the AC and the Strings
to the Inverter
This chapter describes how to connect the inverter to the AC grid, and to the strings of
modules with power optimizers.
If using an inverter with a DC Safety Unit, refer to the instructions in Connecting the AC
and DCStrings to the DC Safety Unit on page 68.
Refer to the technical specifications provided with the inverter.
Grid Connection Guidelines
In most countries, three phase inverters require neutral connection at all times.
In some countries, the three phase inverters can be connected to delta grids; in
other cases, multiple single phase inverters can be used.
Prior to system installation, refer to:
Three Phase Inverters for Delta Grids application note at
https://www.solaredge.com/sites/default/files/se_three_phase_
inverters_for_delta_grids.pdf
Supported Countries application note to confirm compatibility at
http://www.solaredge.com/sites/default/files/se_inverters_
supported_countries.pdf; installing without confirmation
may void the inverter warranty.


For more wiring information refer to the SolarEdge
Recommended AC Wiring Application Note , available on the
SolarEdge website at http://www.solaredge.com/files/pdfs/application-
note-recommended-wiring.pdf.
For recommended circuit breaker size per model refer to
Determining the Circuit Breaker Size on page 82


-Three Phase System Installation Guide MAN-01-00505-1.2
30 Chapter 4: Connecting the AC and the Strings to the Inverter

SolarEdge SE5K Specifications

General

Model	SE5K
Manufacturer	SolarEdge
AC Output Power	5000 W
Rated AC Power	5000 W
Max. Efficiency	98.3%
Cooling	Natural convection
Protection Rating	IP65
Max. Input DC Voltage	480 V
Max. Input Current	11 A
Number of MPP Trackers	1
Warranty	12 years
Communication Interfaces	RS485, Ethernet
AC Voltage	230 V
Operating Temperature Range	-25°C to +60°C
MPPT Voltage Range	330-480V
