Functions 1-4 are used to set inverter output power and reactive power. With restore
means the change will not revert to default after restart. The default setting for functions
1-4 are 100% for output power and 0 for reactive power.
Function 5 “select PF curve” will set a custom power factor curve for different grid
standards. 00 is null. 01 is the PF Curve for VDE4105, 02 is the PF Curve for Brazil.
Other selections are reserved. The default setting is 00.
This function is applicable by maintenance personnel only, wrong operation
will prevent the inverter from reaching maximum power.
Maintenance or replacement could clear or cause a different value of total energy.
Use this function to revise the value of total energy to the same value as before. If the
monitoring website is used the data will be synchronize with this setting automatically.
6.5.6 Calibrate Energy
Figure 6.20 Calibrate Energy
YES=<ENT> NO=<ESC>
Energy:0000000kWh
Press the DOWN key to move the cursor, Press the UP key to revise the value. Press the
ENTER key to execute the setting. Press the ESC key to return to the previous menu.
There are 11 settings in this menu:
1. Grid Filter Set
2. Relay_protect Set
3. ILeak_Protect Set
4. GROUND_Protect Set
5. GRID INTF. 02 Set
6. MPPT Parallel Mode
7. Cnst. Voltage Mode
8. V/FRT Set
9. IgZero_COMP. Set
10. PI Set
11. IgADCheckPRO Set
6.5.7 Special Settings
