6. Operation
User Manual
44
Over frequency load shedding F start range is 59.936-60.036Hz.
The default setting is 60.036Hz.
Descending rate: 5%Pn/0.1Hz.
F stop range: 61-64Hz. Default setting is 62Hz. Recovery rate: 5%Pn/0.1Hz.
Press the Enter key to select the mode or frequency.
Press Up/Down to set. Press ESC to save the settings.
6.5.8.4 10mins Voltage Set
This function is disabled andnot used for the US.
This function is for maintenance personnel only, wrong operation
will prevent the inverter from reaching maximum power.
6.5.8.5 Power Priority
This setting is used to determine the priority between Active Power Control (Watt) and
Reactive Power Control (Var).
This function is for maintenance personnel only, wrong operation
will prevent the inverter from reaching maximum power.
Figure 6.39 Power Priority
YES=<ENT> NO=<ESC>
Select: Var First
Two options are available: Watt First and Var First.
This setting determines the priority when both Volt-Watt and Volt-Var modes are enabled.
6.5.8.6 Initial Settings
This setting will allow the working modes from 6.5.8.1 to 6.5.8.4 to be set back to default.
Figure 6.40 Initial Settings
Work Mode Default
Power Rate Default
To Next Page
