SOLIS S5 Series User Manual

User Manual
I_DC01: +05.0A
I_DC02: +04.9A
...
I_DC20: +05.2A
VPV_Total: Shows input voltage total.
IPV_Total: Shows input current total.
Table 6.1 Information list
Status: Generating
Power: 1488W
Grid Frequency
F_Grid 50.06Hz
Total Energy
0258458 kwh
This Month: 0123kwh
Last Month: 0123kwh
Today: 15.1kwh
Yesterday: 13.5kwh
10 sec
10 sec
10 sec
10 sec
10 sec
10 sec
Status: Shows instant status of the Inverter.
Power: Shows instant output power value.
F_Grid: Shows the grid's frequency value.
Total generated energy value.
This Month: Total energy generated this month.
Last Month: Total energy generated last month.
Today: Total energy generated today.
Yesterday: Total energy generated yesterday.
Display
Duration
Description
Inverter SN
00000000000000
10 sec
Display series number of the inverter.
10 sec
V_C: Shows the grid's voltage value.
I_C: Shows the grid's current value.
10 sec
V_A: Shows the grid's voltage value.
I_A: Shows the grid's current value.
Rea_Power: 000Var
App_Power: VA
10 sec
Rea_Power: Shows the reactive power of the inverter.
App_Power: Shows the apparent power of the inverter.
Work Mode: Volt-watt
DRM NO.:08
10 sec
10 sec
Work Mode: Shows current working mode.
DRM NO.: Shows DRM Number.
I_DC01 : Shows input 01 current value.
I_DC02 : Shows input 02 current value.
...
I_DC20 : Shows input 20 current value.
VPV_Total: 1000.0V
IPV_Total: +99.0A
V_A: 345.7V
I_ A: 109.0A
V_C: 345.0V
I_ C: 109.8A
6. Normal operation
42

SOLIS S5 Series Specifications

General

Number of MPPTs	2
Output Voltage	230 V
Frequency	50/60 Hz
Max. AC Output Power	5000W
Operating Temperature Range	-25°C to +60°C
Rated AC Output Power	2.5 kW / 3 kW / 3.6 kW / 4 kW / 5 kW / 6 kW
Max. AC Output Current	21.7A
Cooling Method	Natural Convection
Humidity	0~100 %
Model	S5 Series
