SOLIS S5 Series User Manual

User Manual
The display shows the 100 latest warn messages (see Figure 6.15). Screens can be scrolled
manually by pressing the UP/ DOWN keys. Press the ESC key to return to the previous menu.
Msg000:
T: 00-00 00:00 D:0000
Figure 6.15 Warning Message
6.6.9 Warning Message
6.6.8 Communication Data
The screen shows the internal data of the Inverter (see Figure 6.14), which is for service
technicians only.
01-05: 01 25 E4 9D AA
06-10: C2 B5 E4 9D 55
Figure 6.14 Communication Data
6.6.6 Yearly Energy
YES=<ENT> NO=<ESC>
Select: 2019
Figure 6.12 Select year for yearly energy
2018: 0017513kWh
2017: 0165879kWh
Figure 6.13 Yearly energy
Press UP/D OWN key to move one date from another.
The function is for checking the energy generation for selected year.
Press DOWN key to move the cursor to day and year, press UP key to change the digit.
Press Enter after the date is fixed.
6.6.7 Daily Records
The screen shows history of changing settings. Only for maintance personel.
6. Normal operation
46

SOLIS S5 Series Specifications

General

Number of MPPTs	2
Output Voltage	230 V
Frequency	50/60 Hz
Max. AC Output Power	5000W
Operating Temperature Range	-25°C to +60°C
Rated AC Output Power	2.5 kW / 3 kW / 3.6 kW / 4 kW / 5 kW / 6 kW
Max. AC Output Current	21.7A
Cooling Method	Natural Convection
Humidity	0~100 %
Model	S5 Series
