SOLIS S5 Series User Manual

User Manual
6.7.13 Debug Parameter
Figure 6.43
Debug Parameter as shown as below:
This section is applicable to maintenance personnel only.
Press the UP/DOWN keys to scroll through items. Press the ENTER key to select.
Press the DOWN key to scroll and press the UP key to change the value.
Press the ENTER key to save the setting. Press the ESC key to cancel.
changes and return to the previous menu.
→
S16DAT1: +0000
S16DAT2: +0000
S16DAT3: +0000
S16DAT4: +0000
S16DAT5: +0000
S16DAT6: +0000
S16DAT7: +0000
S16DAT8: +0000
6.7.14 FAN Test
Figure 6.44
Selecting “Fan Test” displays the sub-menu shown below:
This section is applicable to maintenance personnel only.
Are you sure?
YES=<ENT> NO=<ESC>
Fan Test is a factory test function. Press the ENTER key to start the test.
Press the ESC key to return to the previous menu.
6. Normal operation
63
NOTE
NOTE

SOLIS S5 Series Specifications

General

Number of MPPTs	2
Output Voltage	230 V
Frequency	50/60 Hz
Max. AC Output Power	5000W
Operating Temperature Range	-25°C to +60°C
Rated AC Output Power	2.5 kW / 3 kW / 3.6 kW / 4 kW / 5 kW / 6 kW
Max. AC Output Current	21.7A
Cooling Method	Natural Convection
Humidity	0~100 %
Model	S5 Series
