SOLIS S5 Series User Manual

5. Commissioning
User Manual
5.1 Selecting the appropriate grid standard
5.1.1 Verifying grid standard for country of installation
Solis inverters are used worldwide and feature preset standards for operating on
any grid. Although the grid standard is set at the factory, it is essential the grid standard be
verified for the country of installation before commissioning.
The menu for changing the grid standard or for creating a custom standard is accessible as
described in Section 6.7 and below.
WARNING
Failure to set the correct grid standard could result in improper operation
of the inverter, inverter damage or the inverter not operating at all.
5.2 Changing the grid standard
5.2.1 Procedure to set the grid standard
NOTE
This operation is for service technicians only. The inverter is customized
according to the local grid standard before shipping. There should be no
requirement to set the standard.
NOTE
The “User-Def” function can only be used by the service engineer.
Changing the protection level must be approved by the local utility.
Figure 5.1
Information
Settings
Figure 5.2
YES=<ENT> NO=<ESC>
Password:0000
1. From the main screen on the display, select ENTER. There are 4 sub-menu options, use
the UP/DOWN arrows to highlight ADVANCED SETTINGS. Press enter to select.
2. The screen will show that a password is required. The default password is "0010", press
the DOWN key to move cursor, press the UP key to change the highlighted digit.
36

SOLIS S5 Series Specifications

General

Number of MPPTs	2
Output Voltage	230 V
Frequency	50/60 Hz
Max. AC Output Power	5000W
Operating Temperature Range	-25°C to +60°C
Rated AC Output Power	2.5 kW / 3 kW / 3.6 kW / 4 kW / 5 kW / 6 kW
Max. AC Output Current	21.7A
Cooling Method	Natural Convection
Humidity	0~100 %
Model	S5 Series
