SOLIS S5 Series User Manual

User Manual
OV-G-V1: 236---335V
OV-G-V1-T: 0.1---9S
OV-G-V2: 248---341V
OV-G-V2-T: 0.1---1S
UN-G-V1: 173---236V
UN-G-V1-T: 0.1---9S
UN-G-V2: 132---219V
UN-G-V2-T: 0.1---1S
Startup-T: 10-600S
OV-G-F1: 60.2-63Hz
OV-G-F1-T: 0.1---9S
OV-G-F2: 61-63Hz
OV-G-F2-T: 0.1---9S
UN-G-F1: 57-59.5Hz
UN-G-F1-T: 0.1---9S
UN-G-F2: 57-59Hz
UN-G-F2-T: 0.1---9S
Restore-T: 10-600S
Table 6.2 Setting ranges for User-Def
NOTE
The initial value of the User-Def standard is for reference only. It does
not represent a correct value suitable for use.
Table 6.3 Baseline Inverter Settings
Setting value
Vup-Limit1
528<V<576
Time1
1S
Vup-Limit2
V≥576
Time2
0.16S
Vdw-Limit1
288≤V<422
Time1
2S
Vdw-Limit2
V<288
Time2
0.16S
Fup-Limit1
60.5Hz＜F＜62Hz
Time1
2S
Fup-Limit2
Time2
Fdw-Limit1
Time1
Fdw-Limit2
Time2
F＞62Hz
0.16S
57Hz＜F＜59.5Hz
2S
57Hz＜F
0.16S
480V Rated (L-N)
305<V<333
1S
V≥333
0.16S
166≤V<244
2S
V<166
0.16S
60.5Hz＜F＜62Hz
2S
F＞62Hz
0.16S
57Hz＜F＜59.5Hz
2S
57Hz＜F
0.16S
480V Rated (L-L)
6. Normal operation
48

SOLIS S5 Series Specifications

General

Number of MPPTs	2
Output Voltage	230 V
Frequency	50/60 Hz
Max. AC Output Power	5000W
Operating Temperature Range	-25°C to +60°C
Rated AC Output Power	2.5 kW / 3 kW / 3.6 kW / 4 kW / 5 kW / 6 kW
Max. AC Output Current	21.7A
Cooling Method	Natural Convection
Humidity	0~100 %
Model	S5 Series
