MPI-520 OPERATING MANUAL version 3.4
43
The cell is occupied
for a given type of
measurement.
Measurement (memory cell) is selected by means of and
push-buttons; memory bank is selected by means of
and
push-buttons
.
Storing of data in the memory is performed by means of ENTER
push-button.
If you try to store data in an occupied memory cell, the following
warning message will appear:
After selection of an option by means of and push-buttons,
press ENTER push-button.
Remarks:
- In case of RCD the above warning message will appear also when an attempt is made to store a re-
sult of specific measurement (or result component) that has been made at different preset I
n
current
or for a different preset type of RCD (standard / short-time delay / selective) than the measurements
the results of which are already stored in this cell, despite the fact that the memory space designated
for this result component may be free. When results of measurements made for a different type of
RCD or a different I
n
current are stored, the results concerning a given RCD that have been stored
previously will be lost.
- Complete set of results (main result and supplementary results) for a given measuring function and
preset measurement settings are stored in the memory.
