MPI-
520
OPERATING MANUAL version 3.4
44
4.2
Viewing memory data
Set
the
ro
tary
switch
of
function
s
ele
c-
tion at
M
EM
position.
Select
“
Mem
ory
brow
sing
”
by
means
of
and
push-buttons.
Press
ENTER
push-button.
First of t
he four results stored
in this cell
.
Select m
emory bank by means of
and
push-buttons;
s
e-
lect a m
emory cell by m
eans of
and
push-buttons; pa
r-
ticular results or com
ponents of the result are selecte
d by
means of
F3
and
F4
push-buttons.
The following
table specifie
s the sequence of data s
toring for indiv
idual measurement results
.
45
47
