MPI-520 OPERATING MANUAL version 3.4
65
11 Equipment
11.1 Standard Equipment
Standard set of equipment supplied by the manufacturer includes:
 MPI-520 meter – WMPLMPI520
 set of test leads:
 Uni-Schuko lead with actuation of measurement for insulation resistance testing (cat. III 300 V) – WS-03 –
WAADAWS03
 1.2 m, cat III 1000V test leads with banana plugs – 3 leads (yellow – WAPRZ1X2YEBB, red -
WAPRZ1X2REBB and blue - WAPRZ1X2BUBB)
 15 m-long test leads on reels (WAPRZ015BUBBSZ blue) and 30 m-long test lead (WAPRZ030REBBSZ
red)
 USB interface cable - WAPRZUSB
 accessories
 cat. III 1000 V crocodile clip – 2 clips (yellow K02 – WAKROYE20K02 and red – WAKRORE20K02)
 cat. III 1000 V test prod with banana socket – 3 test prods (yellow – WASONYEOGB1, red –
WASONREOGB1 and blue – WASONBUOGB1)
 earth contact test probe (rod) 30 cm – 2 probes – WASONG30
 carrying case for the meters and accessories – WAFUTL1
 hanging straps for the meter (long – 1.5 m and short – 30 cm) – WAPOZSZEKPL
 operating manual
 calibration certificate
 4 batteries 1.5 V LR14
11.2 Optional Equipment
Additionally, the following items that are not included in the scope of standard equipment can be purchased from
the manufacturer or the distributors:
 red test leads with banana plugs:
 5 m-long– WAPRZ005REBB
 10 m-long – WAPRZ010REBB
 20 m-long – WAPRZ020REBB
 test lead with angle plug (without triggering) (cat. III 300V) – WS-04 – WAADAWS04
 adapter Auto ISO-1000c – cat. III 300V – WAADAAISO10C
 triple phase socket adapter AGT-16P – WAADAAGT16P
 triple phase socket adapter AGT-32P – WAADAAGT32P
 triple phase socket adapter AGT-63P – WAADAAGT63P
 RCD testing adapter TWR-1J – WAADATWR1J
 earth contact test probe (rod) (80 cm) – WASONG80
 cramp – WAZACIMA1
 clamp C-3 – WACEGC3OKR
 software for creating measurement protocols „SONEL Pomiary Elektryczne” (SONEL Electrical measurements) –
WAPROSONPE4
 software for creating drawings, electrical installation diagrams „SONEL PE Schematic” – WAPROSCHEM WAPROSCHEM
 software for creating measurement calculations „SONEL PE Kalkulacje” (SONEL Calculations) – WAPROKALK
Note
The software is supported by the following systems: Windows XP (Service
Pack 2), Windows Vista, Windows 7.
 accumulator package SONEL NiMH 4.8 V 4.2 Ah – WAAKU07
 adapter for accumulator charging Z7 – WAZASZ7
 adapter cable (230 V) – WAPRZLAD230
 cable for charging the accumulator package from the car cigarette lighter socket – WAPRZLAD12SAM
 calibration certificate
