Available Signal Systems
Appendixes
For Details on the available signal system for the DVI-D input signal, see “DVI-D” (page 104) of “Available Signal Formats”.
*: The analog component signal or analog RGB signal from BKM-229X is processed in 720 dots × 2 (1440 dots).
1280×720/24P 750 720 24 Progressive 16:9 SMPTE-296M
720/24P
1280×720/23.98P 750 720 24/1.001 Progressive 16:9 SMPTE-296M
1280×720/25P 750 720 25 Progressive 16:9 SMPTE-296M 720/25P
1280×720/30P 750 720 30 Progressive 16:9 SMPTE-296M
720/30P
1280×720/29.97P 750 720 30/1.001 Progressive 16:9 SMPTE-296M
1280×720/50P 750 720 50 Progressive 16:9 SMPTE-296M 720/50P
1280×720/60P 750 720 60 Progressive 16:9 SMPTE-296M
720/60P
1280×720/59.94P 750 720 60/1.001 Progressive 16:9 SMPTE-296M
2048×1080/24PsF 1125 1080 24 Progressive
1.896:1
2048 × 1080/
24PsF
2.39:1
2048×1080/
23.98PsF
1125 1080 24/1.001 Progressive
1.896:1
2.39:1
2048×1080/24P 1125 1080 24 Progressive
1.896:1
2048 × 1080/
24P
2.39:1
2048×1080/23.98P 1125 1080 24/1.001 Progressive
1.896:1
2.39:1
Signal system
Total lines
per frame
Active lines
per frame
Frame rate
(Hz)
Scanning
format
Aspect
ratio
Standard
Display on the
monitor
