Reassembly
Insert the Coaxial Cable back into front housing cave.
Assemble the Link FPC BtB connector onto SUB Board
Assy.
Assemble the Coaxial Cable connector onto SUB Board
Assy.
Assemble the Battery FPC Connector onto Main PBA.
