– 12 –
3-9. TAPE MECHANISM BLOCK
1 BVTP 3x10
2 BVTP 3x10
3 tape mechanism bloc
k
(MF-S22-117)
3-8. CD MECHANISM BLOCK
1 PWH 2.6x10
2 PWH 2.6x10
3 CD mechanism block
(KSM-213CDM)
