Sony CFD-S22 - PRINTED WIRING BOARDS - POWER SUPPLY SECTION

CFD-S22/S32
– 43 – – 44 –
6-15. PRINTED WIRING BOARDS — POWER SUPPLY SECTION — • Refer to page 18 for Circuit Boards Location.
D901 J-10
D902 I-10
D903 J-9
D904 I-9
• Semiconductor
Location
Ref. No. Location
Note on Printed Wiring Boards:
• X : parts extracted from the component side.
• b : Pattern from the side which enables seeing.
• Abbreviation
E4 : AC 110-120V/220-240V area in E model
E92 : AC 120V area in E model
MX : Mexican model
JE : Tourist model
(Page 34)
1
A
B
C
D
E
F
G
H
I
J
23456789101112
T901
POWER
TRANSFORMER
DRY BATTERY
SIZE " D "
(IEC DESIGNATION R20)
3PCS, 4.5V
DRY BATTERY
SIZE " D "
(IEC DESIGNATION R20)
3PCS, 4.5V
04
925
F901
EXCEPT
E4, JE
MODEL
US,E92,MX MODEL
EXCEPT US,E92,MX MODEL
EXCEPT
E4, JE
MODEL
E4, JE MODEL
E4, JE MODEL
E4, JE MODEL
WHT
RED
BLK
WHT
RED
BLK
CN905
S901
VOLTAGE SELECTOR
220 - 240V
110 - 120V
