11. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3322-672-A CD BOARD, COMPLETE
*******************
< CAPACITOR >
C701 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C702 1-104-664-11 ELECT 47uF 20% 10V
C703 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C704 1-162-968-11 CERAMIC CHIP 4700PF 10% 50V
C705 1-104-665-11 ELECT 100uF 20% 10V
C706 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C707 1-126-925-11 ELECT 470uF 20% 10V
C708 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C709 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C710 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C711 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C712 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C713 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C714 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C715 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C716 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C717 1-104-665-11 ELECT 100uF 20% 10V
C726 1-104-665-11 ELECT 100uF 20% 10V
C730 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C731 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C734 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C735 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C736 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C737 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C738 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C740 1-126-964-11 ELECT 10uF 20% 50V
C744 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C747 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C748 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C749 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C751 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C755 1-104-665-11 ELECT 100uF 20% 10V
C756 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C757 1-104-665-11 ELECT 100uF 20% 10V
C758 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C759 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C760 1-126-964-11 ELECT 10uF 20% 50V
C761 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C770 1-126-964-11 ELECT 10uF 20% 50V
C771 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C780 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C781 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C782 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C783 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C784 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CNP701 1-779-466-11 CONNECTOR, FFC (LIF(NON-ZIF)) 16P
CNP702 1-784-737-11 CONNECTOR, FFC 15P
< DIODE >
D701 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB705 1-469-180-22 INDUCTOR, FERRITE BEAD
FB706 1-469-180-22 INDUCTOR, FERRITE BEAD
< IC >
IC701 8-759-667-96 IC LA9235M
IC702 8-759-669-88 IC LC78641NE
IC703 8-759-591-62 IC BA6998FP
< JUMPER RESISTOR >
JC701 1-216-864-11 METAL CHIP 0 5% 1/16W
JC702 1-216-864-11 METAL CHIP 0 5% 1/16W
JC703 1-216-864-11 METAL CHIP 0 5% 1/16W
JC704 1-216-864-11 METAL CHIP 0 5% 1/16W
< TRANSISTOR >
Q701 8-729-903-46 TRANSISTOR 2SB1132-P
< RESISTOR >
R701 1-216-845-11 METAL CHIP 100K 5% 1/16W
R702 1-216-841-11 METAL CHIP 47K 5% 1/16W
R703 1-216-841-11 METAL CHIP 47K 5% 1/16W
R704 1-216-841-11 METAL CHIP 47K 5% 1/16W
R705 1-216-841-11 METAL CHIP 47K 5% 1/16W
R706 1-216-845-11 METAL CHIP 100K 5% 1/16W
R707 1-216-797-11 METAL CHIP 10 5% 1/16W
R708 1-216-837-11 METAL CHIP 22K 5% 1/16W
R709 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R710 1-216-833-11 RES-CHIP 10K 5% 1/16W
R711 1-216-815-11 METAL CHIP 330 5% 1/16W
% R712 1-216-841-11 METAL CHIP 47K 5% 1/16W
% R712 1-216-843-11 METAL CHIP 68K 5% 1/16W
CD
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• Abbreviation
AR : Argentina model
AUS : Australian model
CND : Canadian model
E4 : AC 110-120V/220-240V area in E model
E92 : AC 120V area in E model
MX : Mexican model
SP : Singapore model
JE : Tourist model
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
– 21 – – 22 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R713 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R714 1-216-833-11 RES-CHIP 10K 5% 1/16W
R715 1-216-835-11 METAL CHIP 15K 5% 1/16W
R716 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R717 1-216-833-11 RES-CHIP 10K 5% 1/16W
R718 1-216-819-11 METAL CHIP 680 5% 1/16W
R719 1-216-819-11 METAL CHIP 680 5% 1/16W
R720 1-216-833-11 RES-CHIP 10K 5% 1/16W
R721 1-216-821-11 METAL CHIP 1K 5% 1/16W
R722 1-216-837-11 METAL CHIP 22K 5% 1/16W
R723 1-216-833-11 RES-CHIP 10K 5% 1/16W
R724 1-216-845-11 METAL CHIP 100K 5% 1/16W
R725 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R726 1-216-821-11 METAL CHIP 1K 5% 1/16W
R727 1-216-821-11 METAL CHIP 1K 5% 1/16W
R728 1-216-821-11 METAL CHIP 1K 5% 1/16W
R729 1-216-821-11 METAL CHIP 1K 5% 1/16W
R730 1-216-821-11 METAL CHIP 1K 5% 1/16W
R731 1-216-821-11 METAL CHIP 1K 5% 1/16W
R732 1-216-821-11 METAL CHIP 1K 5% 1/16W
R733 1-216-821-11 METAL CHIP 1K 5% 1/16W
R735 1-216-841-11 METAL CHIP 47K 5% 1/16W
R736 1-216-821-11 METAL CHIP 1K 5% 1/16W
R737 1-216-813-11 METAL CHIP 220 5% 1/16W
R738 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R741 1-216-841-11 METAL CHIP 47K 5% 1/16W
R742 1-216-845-11 METAL CHIP 100K 5% 1/16W
R751 1-216-821-11 METAL CHIP 1K 5% 1/16W
R752 1-216-821-11 METAL CHIP 1K 5% 1/16W
< SWITCH >
S701 1-762-812-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X701 1-577-253-11 VIBRATOR, CERAMIC (16.9344MHz)
*************************************************************
* A-3322-667-A MAIN BOARD, COMPLETE (S32:US)
* A-3322-670-A MAIN BOARD, COMPLETE (S22:US)
* A-3322-789-A MAIN BOARD, COMPLETE (S22:CND)
* A-3322-791-A MAIN BOARD, COMPLETE (S32:CND)
* A-3322-792-A MAIN BOARD, COMPLETE (S22:E92)
* A-3322-794-A MAIN BOARD, COMPLETE (S32:E92,MX)
* A-3322-862-A MAIN BOARD, COMPLETE (S22:SP,AR)
* A-3322-863-A MAIN BOARD, COMPLETE (S22:AUS)
* A-3322-865-A MAIN BOARD, COMPLETE (S22:E4,JE)
* A-3322-869-A MAIN BOARD, COMPLETE (S32:SP,AR)
* A-3322-968-A MAIN BOARD, COMPLETE (S32:E4)
*********************
7-685-645-79 SCREW +BVTP 3X6 TYPE2 N-S
< CAPACITOR >
C121 1-126-956-11 ELECT 0.1uF 20% 50V
C122 1-162-294-31 CERAMIC 0.001uF 10% 50V
C123 1-126-961-11 ELECT 2.2uF 20% 50V
C124 1-127-876-21 CERAMIC 0.01uF 10% 50V
(US,CND,AUS)
C124 1-127-880-21 CERAMIC 0.022uF 10% 50V
(E4,E92,SP,AR,MX,JE)
C125 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C126 1-126-960-11 ELECT 1uF 20% 50V
C127 1-127-888-21 CERAMIC 0.1uF 10% 50V
(S32)
C128 1-162-294-31 CERAMIC 0.001uF 10% 50V
C129 1-104-664-11 ELECT 47uF 20% 10V
C130 1-104-665-11 ELECT 100uF 20% 10V
C131 1-126-926-11 ELECT 1000uF 20% 10V
C132 1-136-165-00 FILM 0.1uF 5% 50V
C221 1-126-956-11 ELECT 0.1uF 20% 50V
C222 1-162-294-31 CERAMIC 0.001uF 10% 50V
C223 1-126-961-11 ELECT 2.2uF 20% 50V
C224 1-127-876-21 CERAMIC 0.01uF 10% 50V
(US,CND,AUS)
C224 1-127-880-21 CERAMIC 0.022uF 10% 50V
(E4,E92,SP,AR,MX,JE)
C225 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C226 1-126-960-11 ELECT 1uF 20% 50V
C227 1-127-888-21 CERAMIC 0.1uF 10% 50V
(S32)
C228 1-162-294-31 CERAMIC 0.001uF 10% 50V
C229 1-104-664-11 ELECT 47uF 20% 10V
C230 1-104-665-11 ELECT 100uF 20% 10V
C231 1-126-926-11 ELECT 1000uF 20% 10V
C232 1-136-165-00 FILM 0.1uF 5% 50V
C321 1-126-934-11 ELECT 220uF 20% 10V
C322 1-104-664-11 ELECT 47uF 20% 10V
C323 1-126-964-11 ELECT 10uF 20% 50V
C324 1-162-306-11 CERAMIC 0.01uF 20% 16V
C325 1-126-937-11 ELECT 4700uF 20% 16V
C326 1-126-934-11 ELECT 220uF 20% 16V
C327 1-162-294-31 CERAMIC 0.001uF 10% 50V
C328 1-162-294-31 CERAMIC 0.001uF 10% 50V
C329 1-162-306-11 CERAMIC 0.01uF 20% 16V
C331 1-104-664-11 ELECT 47uF 20% 10V
C335 1-104-664-11 ELECT 47uF 20% 10V
(S32)
C501 1-126-933-11 ELECT 100uF 20% 16V
C502 1-162-306-11 CERAMIC 0.01uF 20% 16V
C503 1-104-665-11 ELECT 100uF 20% 10V
C504 1-104-665-11 ELECT 100uF 20% 10V
C505 1-162-306-11 CERAMIC 0.01uF 20% 16V
C506 1-162-199-31 CERAMIC 10PF 5% 50V
C507 1-162-199-31 CERAMIC 10PF 5% 50V
C508 1-126-964-11 ELECT 10uF 20% 50V
C509 1-162-282-31 CERAMIC 100PF 10% 50V
% C510 1-126-964-11 ELECT 10uF 20% 50V
C513 1-128-802-21 CERAMIC 27PF 5% 50V
C514 1-128-802-21 CERAMIC 27PF 5% 50V
C518 1-126-964-11 ELECT 10uF 20% 50V
CD
MAIN
When indicating parts by reference
number, please include the board.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
% R712 DIFFERENCE LIST
MAIN BOARD IC501
CXP83620-025Q CXP83620-026Q
R712 68K 47K
% C510, R600 DIFFERENCE LIST
MAIN BOARD IC501
CXP83620-025Q CXP83620-026Q
C510 10uF 20% 50V no mount
R600 100 5% 1/4W JW
To Next Page
