Sony CFD-S22 - Exploded Views

– 3 –
* 101 A-3322-449-A MAIN BOARD, COMPLETE (S22:US)
* 101 A-3322-471-A MAIN BOARD, COMPLETE (S32:US)
* 101 A-3322-557-A MAIN BOARD, COMPLETE (S22:SP,AR)
* 101 A-3322-559-A MAIN BOARD, COMPLETE (S22:AUS)
* 101 A-3322-601-A MAIN BOARD, COMPLETE (S32:SP,AR)
* 101 A-3322-602-A MAIN BOARD, COMPLETE (S32:AUS)
* 101 A-3322-692-A MAIN BOARD, COMPLETE (S32:E4)
* 101 A-3322-699-A MAIN BOARD, COMPLETE (S22:E4,JE)
* 101 A-3322-735-A MAIN BOARD, COMPLETE (S32:E92,MX)
* 101 A-3322-736-A MAIN BOARD, COMPLETE (S32:CND)
* 101 A-3322-738-A MAIN BOARD, COMPLETE (S22:E92)
* 101 A-3322-739-A MAIN BOARD, COMPLETE (S22:CND)
126 1-792-209-11 WIRE, PARALLEL (16 CORE)
* 127 A-3322-451-A CD BOARD, COMPLETE
128 1-792-208-11 WIRE, PARALLEL (17 CORE)
A-3322-670-A MAIN BOARD, COMPLETE (S22:US)
A-3322-667-A MAIN BOARD, COMPLETE (S32:US)
A-3322-862-A MAIN BOARD, COMPLETE (S22:SP,AR)
A-3322-863-A MAIN BOARD, COMPLETE (S22:AUS)
A-3322-869-A MAIN BOARD, COMPLETE (S32:SP,AR)
A-3322-968-A MAIN BOARD, COMPLETE (S32:E4)
A-3322-865-A MAIN BOARD, COMPLETE (S22:E4,JE)
A-3322-794-A MAIN BOARD, COMPLETE (S32:E92,MX)
A-3322-791-A MAIN BOARD, COMPLETE (S32:CND)
A-3322-792-A MAIN BOARD, COMPLETE (S22:E92)
A-3322-789-A MAIN BOARD, COMPLETE (S22:CND)
1-792-684-11 WIRE (FLAT TYPE) (16 CORE)
A-3322-672-A CD BOARD, COMPLETE
1-792-685-11 WIRE (FLAT TYPE) (15 CORE)
Page FORMER TYPE NEW TYPE
1. EXPLODED VIEWS
! : indicates changed portion.
52
53
#1
#1
#3
#3
MF-S22-117
not supplied
#1
#1
#1
#1
KSM-213CDM
#5
#4
#4
101
116
102
103
104
105
106
121
122
123
123
125
125
125
125
124
124
126
127
128
129
130
131
133
134
@
@
#
#
#
Part No. Description RemarkRef. No. Part No. Description Remark
• Abbreviation
AR : Argentina model
AUS : Australian model
CND : Canadian model
E4 : AC 110-120V/220-240V area in E model
E92 : AC 120V area in E model
MX : Mexican model
SP : Singapore model
JE : Tourist model
