Sony DCR-TRV8 - Flexible Boards Location

2-10E
2-15.FLEXIBLE BOARDS LOCATION
FP-90
(BRT, VOL CONTROL
)
FP-83 (CCD IMAGER)
CONTROL SWITCH BLOCK (CF4550)
CONTROL SWITCH
BLOCK (PS4550)
FP-82
FP-91
FP-84
(TRV10/10E)
FP-87
FP-85
LCD902 (included in FP-88
)
FP-586
(From LOADING MOTOR)
(From DRUM MOTOR)
(From VIDEO HEAD)
FP-242 (From LS CHASSIS)
FP-92 (From LS CHASSIS)
