5-6
Fig. 5-1-3.
CN8607
CN8606
CN8603
CN8608
CN8605
CN2501 CN2907
CN2906
CN2901
CN1810
CN2505
CN2904
CN2903
CN5101
CN3202
CN8610
CN3201
CN2902
VC-217 board
JK-170 board
CK-84
board
Lens
block
FP-82
flexible
CPC-8 jig
i J-6082-388-A j
Extension cable
J-6082-395-A
(80P 0.4mm)
DD-123 board
Viewfinder
Adjustment remote
commander
Color
monitor
Vector
scope
Front panel block
AC power adaptor
i 8.4Vdc)
AC-L10 or
AC-VQ800
Cabinet (R)
Battery
terminal
LANC jack
DC IN jack
Must be connected.
Note: When using the extension
cable, remove the two screws,
and open VC-217 board a little.
MA-358 board
CN7306
AUDIO/VIDEO jack
VIDEO
(Yellow)
AUDIO L
(White)
AUDIO R
(Red)
Terminated
at 75 Ω
Must be connected when using the viewfinder.
Must be connected
when performing
the video system,
color EVF system
or LCD system
adjustments.
