6-8
DSC-F828
1-2. INITIALIZATION OF DATA
1-2-1. INITIALIZATION OF DATA
1. Initializing All Pages Data
By performing the following procedure, data of all the pages will
be initialized.
Initializing Method:
1) Select page: 00, address: 01, and set data: 01.
2) Click [Sector Write] on the SEUS screen to display the SEUS
SECTOR WRITE screen.
3) Check that the SET ID is 03.
4) Click [All] of the ALL SELECT buttons to select all pages.
(Fig. 6-1-8. A)
5) Click [Write] to write the initializing data to the EEPROM of
the camera.
6) Wait for 2 sec.
7) Click [Close] to close the SEUS PAGE EDIT screen.
Modification of 4F, 8E Page Data
If all page data have been initialized, change the data of the Fixed
data-2 address shown in the following tables by manual input.
1) Select page: 00, address: 01, and set data: 01.
2) Click [Page] on the SEUS screen, and input 4F or 8E.
3) Click [Address], and input the Fixed data-2 address.
4) Click [Set], and input the new data.
Note: New data for changing are not shown in the table because they
are different in destination. When changing the data, copy the
data built in the same model. If copy the data built in the different
model, the camera may not operate.
5) Repeat steps 2 to 4 until all data of the Fixed data-2 addresses
are changed.
6) Click [Save] to write the changed data to the EEPROM of the
camera.
7) Wait for 2 sec.
Processing after Completing Initializing of data
Order Page
Address
Data Procedure
1 20 00 29 Set the data.
2 20 01 29 Set the data.
3 Check Receive Paket Error is
displayed on the SEUS screen.
4 Turn on the power of the camera.
5 Click [Connect] on the SEUS
screen.
2. Initializing Single Page Data
By performing the following procedure, data of the page that you
want to initialize will be initialized.
Initializing Method:
1) Select page: 00, address: 01, and set data: 01.
2) Click [Sector Write] on the SEUS screen to display the SEUS
SECTOR WRITE screen.
3) Check that the SET ID is 03.
4)
Click [All] of the option buttons of the target page. (Fig. 6-1-8.
B
)
5) Click [Write] to write the initializing data to the EEPROM of
the camera.
6) Wait for 2 sec.
7) Click [Close] to close the SEUS PAGE EDIT screen.
Note: When 4F page or 8E page is initialized, perform Modification of
4F, 8E Page Data. (Refer to 1. Initializing All Pages Data.)
Processing after Completing Initializing of data
Order Page
Address
Data Procedure
1 20 00 29 Set the data.
2 20 01 29 Set the data.
3 Check Receive Paket Error is
displayed on the SEUS screen.
4 Turn on the power of the camera.
5 Click [Connect] on the SEUS
screen.
3. 2F Page Adjustment Address
Table. 6-1-2.
4. 4F Page Adjustment Address
Table. 6-1-3.
B
A
Fig. 6-1-8.
Address Remark
Initial value
Address Remark
Initial value
46
47
88
94
95
96
97
A1
00
00
00
00
Fixed data-2
Fixed data-2
Fixed data-2
Recording counter
(Refer to Record of Use check
of SERVICE MODE(Page 6-42).)
Fixed data-2
Address Remark
Initial value
Address Remark
Initial value
23 80 Test mode
