6-7
DSC-F828
4. Preparing the Flash Adjustment Box
A dark room is required to provide an accurate strobe adjustment.
If it is not available, prepare the flash adjustment box as given below;
1) Provide woody board A, B and C of 15 mm thickness.
woody board A (2 sheets)
400 mm
woody board B (2 sheets)
370 mm
woody board C (1 sheet)
700 mm
513 mm 513 mm 700 m
m
700 mm730 mm
2) Apply black mat paint to one side of woody board A and B.
3) Attach background paper (J-2501-130-A) to woody board C.
4) Assemble so that the black sides and the background paper side
of woody board A, B and C are internal. (Fig. 6-1-7.)
Fig. 6-1-6.
woody board A
woody board B
woody board B
woody board C
woody board
A
Fig. 6-1-7.
