Sony DSC-F828 Adjustment

6-39
DSC-F828
2-2. SERVICE MODE
1. Setting the Test Mode
Page 2F Address 23
Data Function
80 Normal
11 Forced STILL mode power ON
12 Forced PLAY mode power ON
04 Forced MOVIE mode power ON
• Before setting the data, select page: 00, address: 01, and set
data: 01.
• For page 2F, the data set is recorded in the non-volatile memory
by saving data. In this case, take note that the test mode will
not be exited even when the main power is turned off.
• After completing adjustments/repairs, release the data setting .
1)Select page: 00, address: 01, and set data: 01.
2)Select page: 2F, address: 23, and set data: 80.
3)Save the data.
4)Wait for 2 sec.
5)Select page: 00, address: 01, and set data: 00.
2. Bit value discrimination
Bit values must be discriminated using the hexadecimal data for
following items. Use the table below to discriminate if the bit value
is “1” or “0”.
Examples: If the hexadecimal data is “8E”, the bit values for bit7 to bit4
are shown in the A column, and the bit values for bit3 to bit0
are shown in the B column.
bit3 to bit0 discrimination
bit7 to bit4 discrimination
Hexadecimal data
Display on the
adjustment
remote
commander
0
1
2
3
4
5
6
7
8
9
A (
A
)
B (
b
)
C (
c
)
D (
d
)
E (
E
)
F (
F
)
Bit values
bit3
or
bit7
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
bit2
or
bit6
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
bit1
or
bit5
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
bit0
or
bit4
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
A
B
